Do your part for the environment and your business: transform used tires into valuable resources with our innovative equipment. Produce eco-friendly crumb rubber for playgrounds, running tracks, and more. Manufacture high-quality rubber tiles –- a sustainable flooring solution. Reduce waste, open new revenue streams, and elevate your brand with our tire recycling solutions.

ATR - 300

TIRE RECYCLING PLANT

Required Space (excluding storage):	80 m2
Height:	4 meters
Width:	4 meters
Length:	18 meters
Temperature Range:	0 to 40°C
Power Requirements:	160 kW (average consumption 80 kW/h)
Input Capacity:	500 kg/h
Output Capacity (Rubber Crumb):	350 kg/h (3 fractions)
Textile Cord Output:	60 kg/h
Metal Cord Output:	90 kg/h
Annual Processing Capacity:	Up to 4,000 tons
Maximum Tire Diameter:	1,200 mm
Staffing Requirements:	2-3 people per shift

ATR - 500

TIRE RECYCLING PLANT

Electric power (required)	200 kW
The average level of power consumption	100 kW / h
Performance inlet line	up to 750 kg of raw material/hour
Performance line output (average)	500 kg of crumb / hour, 3 fraction from 0 to 6 mm
Out of textile cord	90 kg / h
The output of the metal cord	160 kg / hour
The annual processing capacity of the tire when loading 300 days a year, 20 hours a day	6,000 tons of tires
The maximum size of recycled tires	1200 mm
Number of staff per shift	3-4 people
Requirements for premises Occupied area (excluding storage area)	80 m2
Height	4m
Width	4m
Length	20m
The recommended mode of operation	2 changes of 10 - 12 hours in view of maintenance
Temperature conditions	0 to + 40C°

ATR - 1000

TIRE RECYCLING PLANT

Electric power	250 kW
The average level of power consumption	120 kW/h
Performance inlet line	to 1000 kg feed/hour
Performance line outlet (medium depends on the feed composition)	700 kg of chips/hour, 4 fractions from 0 to 6 mm
Out of textile cord	120 kg / hour
The output of the metal cord	180 kg / hour
The annual processing capacity of the tire when loading 300 days a year, 20 hours a day	Up to 6.000 tons
The maximum size of recycled tires	diameter 22"
Number of staff per shift	4 - 5 people
Occupied area (excluding storage area)	150 m2
Height	4,5m
Width	4,5m
Length	22 m
The recommended mode of operation	2 shifts of 8-10 hours
Temperature conditions	from 0 to +40C°

ATR KING

TIRE RECYCLING PLANT

Guillotine for cutting of large-sized tires	1
Bootable belt conveyor	1
Primary system of shredding	2
Transport fan	3
Magnetic separation system	3
Small cyclones collectors	3
The system of pneumatic transport	1
Magnetic separation system	4
Complex of crushers	1
The system of vibrating screens	2
Cyclone collector	1
Dust removal system	1
Electrical equipment, wiring, electrical and other.	1
The communication system and the protection of steel structures	1
Belt conveyor for metal cord	1
Hydraulic shears for cutting of chips and truck tires	1

ARFC OPTIMAL

RUBBER TILES MAKING MACHINE

Hydraulic press	1 pcs.
Carts for molds	6 pcs.
Mixer for the preparation of raw materials	4 pcs.
Stand for mixer	4 pcs.
Moulding table	1 pcs.
Molds	60 pcs.
Heat chamber	1 pcs.
Temperature sensor	1 pcs.
Extractor hood	1 pcs.
Panel for temperature control	1 pcs.
Matrix for making technological apertures in the tiles	1 pcs.
Libra	3 pcs.
Installation tools	one set.
Tools	one set.
Stand for products	1 pcs.

ARFC - MASSIVE

RUBBER TILES MAKING MACHINE

Hydraulic press	1 pcs.
Carts for molds	10 pcs.
Mixer for the preparation of raw materials	6 pcs.
Stand for mixer	6 pcs.
Moulding table	2 pcs.
Molds	100 pcs.
Increased heat chamber	1 pcs.
Temperature sensor	1 pcs.
Extractor hood	1 pcs.
Panel for temperature control	1 pcs.
Matrix for making technological apertures in the tiles	1 pcs.
Libra	4 pcs.
Installation tools	one set.
Tools	one set.
Stand for products	1 pcs
